| Model no. | No. of segments | Features | Interface | Operating voltage | Vlcd (max.) |
| SA3621G | 32 seg X 2,3,4 com | Low cost general purpose | 3/4 SPI | 2.4V - 5.2V | Vdd |
| SA3622G | 36 seg x 2,3,4 com | Low current. High ESD. VA use | IIC | 2.4V - 5.2V | Vdd |
| SA3630G | 31 seg x 1 com |
Static drive 250 Hz frame frequency VA use |
3/4 SPI | 2.4V - 5.2V | Vdd |
| SA3631G | 32 seg X 2,3,4 com | 1/2 duty, 128Hz, 1/3 duty 85Hz frame frequency, VA use | 3/4 SPI | 2.4V - 5.2V | Vdd |
| SA3860G | 160 seg x 1 com | Full static drive. Low current 2uA, High frame frequency VA use | SPI / IIC | 1.8V - 5.5V | 5.5V |
| SA38602G | 274 seg x 1 com | Full static drive. Low current 4uA, High frame frequency VA use | SPI / IIC | 1.8V - 5.5V | 5.5V |
| SA38603G | 384 seg x 1 com | Full static drive. Low current 6uA, High frame frequency VA use | SPI / IIC | 1.8V - 5.5V | 5.5V |
| SA3633G | 80 seg X 1, 2, 3, 4 com | High frame frequency VA use | IIC | 1.8V - 5.5V | 6V |
| SA3636G | 160 seg X 1, 2, 3, 4 com | High frame frequency VA use | IIC | 1.8V - 5.5V | 6V |
SA3622G
-
36 seg x 2,3,4 com
-
IIC interface
-
Vdd, Vlcd: 2.4V to 5.5V
-
Low operating current
-
VATN applicatons
SA3630G
-
31 SEG full static drive
-
Vdd, Vlcd: 2.4V to 5.2V
-
SPI interface
-
250Hz frame frequency, VA use
SA3631G
-
32 seg x 2,3,4 com
-
Vdd, Vlcd: 2.4V to 5.2V
-
SPI interface
-
128Hz frame frequency for 1/2 duty, 85Hz for 1/3 duty, VA use
SA3860G
-
160 seg full static drive
-
IIC / SPI interface
-
Vdd: 1.8V to 5.5V
-
Vlcd: 1.8V to 5.5V
-
2uA operating current
-
250Hz max. frame frequency, VATN applications
SA38602G
-
274 seg full static drive
-
IIC / SPI interface
-
Vdd, Vlcd: 1.8V to 5.5V
-
Low current, 4uA operating.
-
250Hz max. frame frequency, VA use
SA38603G
-
384 seg full static drive
-
IIC / SPI interface
-
Vdd, Vlcd: 1.8V to 5.5V
-
Low current, 6uA operating.
-
250Hz max. frame frequency, VA use
