The SA38602G is a versatile 274 segment (138 seg x 1 com + 136 seg x 1 com, Dual Chip) static drive.
Static drive means 100% drive time of LCD patterns.
It provides very good contrast and wide view angle compared with 1/4 duty LCD drivers at similar cost.
High frame frequency makes it suitable for VA applications.
SA3860G has very low power consumption and operating current can be as low as 4uA
Applications
VATN Display
Home Appliances
Electric Motorcycle
Industrial Meters
Features
- 274 segment static drive outputs
- Built in two independent (138 x 1+136 x 1) bit display RAM
- Vdd, VLCD: 8V - 5.5V
- Interface: 3-line / 4-line serial and I2C
- Wide range frame frequency control by software (1.6Hz~259Hz), suitable for VA displays and super low operating current
- High transparency for negative displays with backlight due to static
- Low power consumption: 4.0uA - 30uA operating current
- 1000hr 85C, 85RH test guaranteed
- Package: COG
