The SA3860G is a versatile 160 segment static LCD driver.
Static drive means 100% drive time of LCD patterns.
It provides very good contrast and wide view angle compared with 1/4 duty LCD drivers at similar cost.
SA3860G has very low power consumption and operating current can be as low as 2uA
Applications
VATN Display
Home Appliances
Electric Motorcycle
Industrial Meters
Features
- 160 segment static drive outputs
- Built-in 160 x 1 bit display RAM
- Vdd, VLCD: 8V - 5.5V
- Internal voltage doubler for VLCD up to 5.5V with 3V Vdd.
- V0adj pin for adjusting VLCD operating voltage
- 3-line / 4-line serial interface and I2C serial interface
- Wide range frame frequency control by software (1.6Hz~259Hz), suitable for VA displays and super low operating current
- High transparency for negative displays with backlight due to static
- Low power consumption: 0uA - 30uA operating current
- 1000hr 85C, 85RH test guaranteed
- Package: COG
